C500-5X

Cost-effective entry into the 5-sided and 5 axis simultaneous machining

Features
  • - Cross slide design
  • - One-piece cast iron machine bed ensures maximum stability
  • - Roller gear cam drive rotary table
  • - Standard with direct drive spindle 12000 rpm
Specifications
  • Table Size: 500x500mm
  • Spindle Speed: 12000rpm
Category: 5-Axis High-Speed

Cross slide design machining center with one-piece cast iron machine bed for maximum stability. Features roller gear cam drive rotary table and standard direct drive spindle.

  • Roller gear cam drive rotary table
  • Full enclosed splash guard
  • Direct drive spindle 12000rpm
  • 40 pockets chain type tool changer
  • Chain type chip conveyor
  • Spindle oil cooler
  • Air-conditioned electrical cabinet
  • Rigid tapping
  • Ethernet, CF card and USB interface
  • Automatic lubrication system
  • Coolant system
  • Air blast during cutting
  • LED working lamp
  • End of program light
  • Electrical handwheel (MGP)
  • Direct drive spindle 15000rpm
  • Bult-in spindle 20000rpm HSK A63, 20/24kW_35/42Nm
  • Linear scales on X/Y/Z axis
  • Rotary encoder on A/C axis
  • CTS Coolant Through Spindle + ATS
  • Workpiece probe
  • Tool probe
  • Oil mist collector
  • Oil skimmer
  • Extra 200GB SSD program memory
